Iron cast weights
Description
Our new FP-BLL combine pleasing, modern design with outstanding quality, durability numerous practical advantages and a wide range of capacities.
Cast iron weights are resistant to impact, time, crack propagation and deformation, which is a guarantee of quality.
Very cleverly designed, it incorporates a generously proportioned toolbox compartment with a capacity of some 80 litres.
ADVANTAGES
- Aesthetically pleasing
- 80L Storage space on the top
- With 400, 600 and 800kg add-on weights available on the front and 500kg underneath, provides the weight capacity to suit your tractor and application.
Technical features
Dimensions
| Model | A (mm) | B (mm) | C (mm) | D (mm) |
|---|---|---|---|---|
|
1000kg |
1124 |
670 |
1065 |
580 |
|
ADD 400kg |
1092 |
191 | 432 | / |
|
ADD 500kg (fixation par le dessous) |
968 |
512 |
420 |
90 |
| ADD 600kg | 1096 | 256 | 437 | / |
| ADD 800kg* | 1096 | 327 | 515 | / |
Standard equipment
- Front linkage fixing including:
- 3rd link ⌀25mm pin - Coupling jaw to the 3rd link
- 80LStorage space integrated
- Box size : 980 x 230 x 310
OPTIONAL EQUIPMENT
- 400, 600 or 800kg additional front weight to be mounted with weight holder (case iron range B)
- 500kg additional weight to be mounted from below
- Sliding elements make it possible to adjust wings size according to the size of the tractor
- Fp-Box storage box
- Safety kit with position indicators, limiting lights, reflective strips
Tractor-compatible
